Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone 14 Plus Screen Replacement Guide

Here are some tools you may need to help you complete the repair.

Please note: A discounted simple toolset with the tools you need is available in a pop-up when you add this product to cart

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2 and Y000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
• 1mm Tesa Tape 61395 Roll Double Sided Adhesive Tape (50m)
• iGadget Plastic Alcohol 200mL Bottle with Pump Top

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• Track your screws, they are different lengths: two 6.8mm P2 pentalobe screws at the bottom, one 0.8mm Y000 on the display connector bracket, one 1.0mm Y000 on the front sensor connector bracket, and two 1.4mm Y000 on the front sensor bracket. Use a screw mat to keep them in place
• Remove the two pentalobe screws beside the Lightning port, warm the bottom edge and lift the screen from the front with a suction cup (not through the back glass). Slide picks under the plastic bezel, no more than 3mm deep (2mm on the left edge, where the display cables run). The screen opens like a book from the right side, hinged on the left, with two clips along the top edge
• On the iPhone 14 Plus the battery connector sits under the back glass, so it is not disconnected for a screen swap - keep the phone powered off and use only plastic tools near the connectors. Disconnect the display cable first, then the front sensor cable, each under a small bracket, and make sure both brackets latch back on reassembly
• Carefully transfer the front sensor assembly (proximity sensor, ambient light sensor, flood illuminator and microphone) from your old screen - the earpiece stays in the phone. Warm the top edge and use a spudger to gently pry underneath the flex cable to loosen the glue. If the flex cable breaks, you will lose Face ID features. Watch the video above before attempting removal
• When fitting the new screen, hook the clips along the top edge in first, then press the rest of the screen down
• Test touch, display, earpiece, proximity and Face ID before sealing the phone, and don't peel off the protective film or any stickers until it's all working
• Opening your iPhone 14 Plus breaks its factory water-resistance seal. Clean off the old adhesive with isopropyl alcohol and fit the new screen gasket adhesive included in the box when you reassemble it.
• Once the repair is finished, turn True Tone on in Settings > Display & Brightness (iOS 18 or later)
