Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone 14 Screen Replacement Guide

Here are some tools you may need to help you complete the repair.

Please note: A discounted simple toolset with the tools you need is available in a pop-up when you add this product to cart

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2 and Y000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
• 1mm Tesa Tape 61395 Roll Double Sided Adhesive Tape (50m)
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iGadget Universal Magnetic Work Project Mat with Marker (30cm x 25cm)

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• The battery can't be disconnected for this repair. Keep the phone powered off, keep metal tools away from the battery and board, and never bend, crush or puncture the battery.
• Track your screws on a screw mat or tape them to a drawing of your phone. This repair uses two 6.8mm pentalobe screws and four Y000 tri-point screws (two 0.9mm and two 1.4mm). Keep them apart so each goes back in the right place
• Remove the two 6.8mm pentalobe screws beside the Lightning port, then heat the bottom edge to soften the adhesive
• The screen comes off the front, not through the removable back glass. Slide picks under the plastic bezel, not between bezel and panel, no deeper than 3mm (2mm along the left edge). It opens from the right like a book - display cables on the left, two clips along the top
• Disconnect the display connector first, then the front sensor connector - each sits under a small bracket held by one 0.9mm Y000 tri-point screw. When reconnecting, line each up and press one side, then the other, until it clicks - don't force it - and make sure both brackets latch back
• Transfer the front sensor assembly from your old screen - the earpiece stays in the phone. Remove its bracket (two 1.4mm Y000 screws), warm the top edge, gently lift the flex with a spudger or opening card. A broken cable loses Face ID
• When fitting the new screen, hook the clips along the top edge in first, then press the rest of the screen down
• Test touch, display, proximity (screen turns off during a call), auto-brightness and Face ID before sealing the phone, and don't peel off the protective film or any stickers until it's all working
• Clean off all the old adhesive with isopropyl alcohol and fit the new screen adhesive supplied in the box to keep dust and moisture out
• This screen supports IC transfer - a micro-soldering specialist can move the display IC from your old screen onto this one.
• Once the repair is finished, turn True Tone on in Settings > Display & Brightness and check auto-brightness is working (iOS 18 or later)
