iPhone 12 Pro Max Screen Replacement | IC3 In-Cell LCD
iPhone 12 Pro Max Screen Replacement | IC3 In-Cell LCD
In Stock
Regular price
NZ$68.99
Regular price
Sale price
NZ$68.99
Unit price
per
inc GST
iPhone 12 Pro Max Screen Replacement | IC3 In-Cell LCD
iPhone 12 Pro Max Screen Replacement | IC3 In-Cell LCD
In Stock
Regular price
NZ$68.99
Regular price
Sale price
NZ$68.99
Unit price
per
inc GST
DIY DIFFICULTY
ModerateAbout 1 to 2 hours
Held in by two pentalobe screws and adhesive. The earpiece and sensor flex move to the new screen.
- iPhone 12 Pro Max screen replacement with a REPART Premium TFT LCD and high colour intensity
- Fixes cracked glass, lines, flicker and dead touch, with In-Cell technology that puts the LCD and touchscreen in the same sensor layer for a quicker, stable touch system
- Compatible with iPhone 12 Pro Max models: A2342, A2410, A2411 & A2412
Frequently Bought Together
Frequently Bought Together
Product Details
Cracked your iPhone 12 Pro Max screen? Or is the display showing lines, black patches or flicker, or is it not responding to touch? This REPART in-cell LCD screen replacement swaps the complete display and touch digitiser on the iPhone 12 Pro Max (A2342, A2410, A2411 and A2412), with the metal LCD shield plate already fitted to the back.
Also available for the iPhone 12 Pro Max: Soft OLED (OLED picture quality)
It is built for the iPhone 12 Pro Max: a 6.7-inch, 2778 x 1284 panel at 458 ppi, with 550-650 cd/m2 brightness and a 95-105% sRGB colour gamut. The iPhone 12 Pro Max came with an OLED screen, so this LCD is a budget friendly alternative. It has a slightly thicker border and lower contrast than OLED.
- IN-CELL TECHNOLOGY - The LCD and touchscreen are in the same layer, so touch is quick and reliable, with even colour and brightness right to the edges. No delayed touch, shadows or dark patches like cheap out-of-cell (OOC) screens.
- PREMIUM LCD - A premium TFT LCD with brighter colours, whiter whites and darker blacks than other aftermarket LCD screens. One integrated driver chip runs display and touch together, for better power efficiency.
- PRECISE FIT - Chip-on-Flex (COF) bonding keeps the border slim for an LCD, and the dimensions and cutouts match the Apple screen, so installation is a breeze.
- QUALITY TESTED - Built from quality materials and components, and rigorously tested so REPART screens outperform standard LCD screens.
- TRUE TONE CAPABLE - With iOS 18 or later, True Tone works with this screen without a transfer machine.
- COST EFFECTIVE - A much cheaper alternative to Apple's OLED screens, saving you money.
Part Includes:
- iPhone 12 Pro Max REPART In-Cell LCD Screen and Touch Digitiser Assembly
- Metal LCD shield plate (pre-installed)
- iPhone 12 Pro Max Screen Gasket Adhesive
- 12 Month Warranty
Please Note
Does NOT fit iPhone 13 Pro Max, 14 Plus, 12 or 12 Pro. The look-alike 13 Pro Max has a smaller notch. Check in Settings, General, About for your model.
Please Note
Face ID and True Tone (iOS 18 or later) keep working once you move the front sensor assembly across from your old screen.
Please Note
Third party LCD screen, not an official Apple product. iOS will list it as an Unknown Part. This is normal.
Specifications
- Screen Type: TFT-LCD
- Screen Brand: REPART
- Touch System Type: In-Cell
- Driver IC: TDDI integrated chip
- Backlight Type: ESR
- Display Size: 6.7"
- Refresh Rate: 60Hz
- Polariser Viewing Angle: 360 degrees
- True Tone Capable: Yes (iOS 18 or later)
- IC Transferable: Yes
- Pixel Density: 458ppi
- Resolution: 1284 x 2778
- Colour Temp: 6500-7500k
- Colour Gamut: 95-105% sRGB
- Colours: Black
- Brightness: 550-650 cd/m2
- Brightness Uniformity: 90%
- Glass Rating: 9H, oleophobic (anti-fingerprint) coating
- Pairing: Not paired. Shows as an Unknown Part, but the screen works normally.
- Warranty: 12 Months
How do I find my Model number?
iPhone 12 Pro Max
Compatible Model Numbers
iPhone 12 Pro MaxModel Number (A Number)
- A2342
- A2410
- A2411
- A2412
iPhone 12 Pro Max Model NumbersHow do I find my Model number?
Model Identifier
- iPhone13,4
EMC Number
- EMC 3548
- EMC 3549
- EMC 3550
Device Number (M Number)
- MG8X3
- MG8Y3
- MG903
- MG913
- MG923
- MG933
- MG943
- MG953
- MG963
- MG973
- MG983
- MG993
- MG9A3
- MG9C3
- MG9D3
- MG9E3
- MG9F3
- MG9G3
- MG9H3
- MG9J3
- MG9K3
- MG9L3
- MG9M3
- MG9N3
- MG9P3
- MG9Q3
- MG9R3
- MG9T3
- MG9U3
- MG9V3
- MG9W3
- MG9X3
- MG9Y3
- MGA23
- MGA33
- MGA43
- MGA73
- MGA93
- MGAA3
- MGAF3
- MGAH3
- MGAJ3
- MGAM3
- MGAQ3
- MGAR3
- MGAU3
- MGAW3
- MGAX3
- MGC03
- MGC13
- MGC23
- MGC33
- MGC43
- MGC53
- MGC63
- MGC73
- MGC93
- MGCA3
- MGCC3
- MGCE3
- MGCF3
- MGCG3
- MGCH3
- MGCJ3
- MGCK3
- MGCL3
- MGCM3
- MGCN3
- MGCP3
- MGCQ3
- MGCR3
- MGCT3
- MGCU3
- MGCV3
- MGCW3
- MGCX3
- MGCY3
- MGD03
- MGD13
- MGD23
- MGD33
- MGD43
- MGD53
- MGD63
- MGD73
- MGD83
- MGD93
- MGDA3
- MGDC3
- MGDD3
- MGDE3
- MGDF3
- MGDG3
- MGDH3
- MGDK3
- MGDL3
More info Less info
Installation Help
Check out the video above or the step by step guide below for assistance with this repair
iFixit iPhone 12 Pro Max Screen Replacement Guide
Here are some tools you may need to help you complete the repair.
Please note: A discounted simple toolset with the tools you need is available in a pop-up when you add this product to cart
- P2 Metal Pentalobe 0.8mm Screwdriver Tool
- Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
- #000 1.5mm Metal Phillips Screwdriver Tool (PH000)
- Large Blue Suction Cup Opening Tool
- Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
- iGadget Plastic Triangle Opening Picks (set of 5)
- 5x iGadget Plastic Flexible Opening Cards
- Nylon Antistatic Spudger Pry Tool
- Or get the P2, Y000 and #000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
- iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
- uFix iOpener Microwaveable Heated Bag Opening Tool
- iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email
- Drain the battery below 25% before you start on this repair
- Always power down your device prior to working on it
- Track your screws, as they are different lengths: two 6.7mm P2 pentalobe screws at the bottom, 1.1mm Y000 screws on both connector covers, and two 1.3mm Phillips, one 1.8mm shouldered Y000 and one 1.1mm Y000 on the earpiece bracket. Use a screw mat
- Warm the edges, then lift the screen with a suction cup and picks no more than 3mm deep (2mm on the left edge, where the display cables run). It opens like a book from the right, hinged on the left - do not lift it from the top
- Always unplug the battery before you remove any other parts. Keep metal tools away from the battery, and never bend, crush or puncture it.
- Remove the four Y000 screws on the battery and display connector cover and disconnect the battery first, then the display cable. Then remove the front sensor cover and unplug the front sensor cable before attempting any component removal
- Carefully transfer the earpiece speaker and front sensor assembly from your old screen - warm the top edge and use a spudger to gently pry underneath the flex cable to loosen the glue. It is paired to your iPhone, so if the flex cable or flood illuminator breaks, you will lose Face ID features. Watch the video above before attempting removal
- Test touch, display, earpiece, proximity and Face ID before sealing the phone, and don't peel off the protective film or any stickers until it's all working
- Opening your iPhone 12 Pro Max breaks its factory water-resistance seal. Fit the new screen gasket adhesive included in the box when you reassemble it.
- Once the repair is finished, turn True Tone on in Settings > Display & Brightness (iOS 18 or later)
What’s In The Box
- 1x iPhone 12 Pro Max REPART In-Cell LCD Screen Replacement (metal LCD shield plate pre-installed)
- 1x iPhone 12 Pro Max Screen Gasket Adhesive
