Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone 13 mini Screen Replacement Guide

Here are some tools you may need to help you complete the repair.

Please note: A discounted simple toolset with the tools you need is available in a pop-up when you add this product to cart

• #000 1.5mm Metal Phillips Screwdriver Tool (PH000)
• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2, Y000 and #000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iGadget Universal Magnetic Work Project Mat with Marker (30cm x 25cm)

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• Track your screws on a screw mat or tape them to a drawing of your phone. This model uses 1.2mm, 1.4mm and 1.8mm Y000 screws plus one 1.4mm Phillips screw - a long screw in a short hole can damage the logic board
• Remove the two 6.8mm pentalobe screws beside the Lightning port, then heat the bottom edge to soften the adhesive
• Insert picks under the plastic bezel, never at the seam between bezel and display, no deeper than 3mm (2mm along the left edge). The screen opens from the right-hand side like a book - the display cables are on the left. Expect some resistance from the clips along the top edge
• Always unplug the battery before you remove any other parts. Keep metal tools away from the battery, and never bend, crush or puncture it.
• Remove the single 1.2mm Y000 screw and the connector cover, then disconnect the battery before the display cable. The front sensor cable sits under its own cover, held by one 1.4mm Phillips (it strips easily), one 1.8mm Y000 and one 1.2mm Y000 screw
• Transfer the front sensor assembly from your old screen - the earpiece stays in the phone. Remove its metal cover (three 1.4mm Y000 screws), warm the top edge for 1-2 minutes, then gently lift each sensor with a spudger or opening card, keeping adhesive off the sensors and microphone when refitting. A broken cable loses Face ID
• Make sure the phone is on iOS 15.2 or later, otherwise Face ID can stop working after a screen replacement
• When reconnecting a cable, press one end until it clicks, then the other - never press in the middle. If the screen or touch does not work, disconnect the battery and reseat the display cable
• Test touch, display, proximity (screen turns off during a call) and Face ID before sealing the phone, and don't peel off the protective film or any stickers until it's all working
• Clean off all the old adhesive with isopropyl alcohol and fit the new screen adhesive supplied in the box to keep dust and moisture out. Seat the top edge clips first when closing the phone
• Once the repair is finished, turn True Tone on in Settings > Display & Brightness (iOS 18 or later)
