Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone 17 Pro USB-C Port Assembly Replacement Guide

Here are some tools you may need to help you complete the repair.

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• #000 1.5mm Metal Phillips Screwdriver Tool (PH000)
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2, Y000 and #000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• Metal Stand-Off 2.5mm Screwdriver Tool
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adatper by Dottorpod
• 2mm Tesa Tape 61395 Roll Double Sided Adhesive Tape (100m)
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iPhone 17 Pro Front OEM Waterproof Adhesive
• iPhone 17 Pro Replacement Battery Adhesive

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• Track your screws, they are many different lengths: two 7.5mm P2 pentalobe screws at the bottom edge, the battery tray screws, two 4.0mm standoff screws on the Taptic Engine, and on the port itself 1.2mm to 3.3mm screws, two of them on the bottom edge of the frame. Draw a picture of your phone and tape the screws to the right places or use a screw mat
• Remove the two pentalobe screws beside the USB-C port, warm the bottom edge and lift the screen from the front with a suction cup, then slide opening picks around the edges to separate the adhesive. Only insert the picks a few millimetres so you don't cut the screen cables
• Make sure you always unplug the battery before attempting any component removal. Remove the small connector covers, disconnect the battery first, then the screen, and reconnect the battery last
• The logic board stays in, but the battery, loudspeaker and Taptic Engine come out first, and the separate main microphone beside the port is unscrewed and lifted off. The port flex unplugs from two stacked press connectors at the bottom left of the logic board. Fit new battery adhesive when the battery goes back in
• The port is glued to the frame. Warm it before prying, separate the microphone on the left of the port with an opening pick, and don't tear the large black graphite sheet inside the frame
• The connector to the logicboard can be tricky to align correctly so it fits into place. We recommend taking a pencil and tracing the original charging port so you know exactly where it gets positioned and lining the new charger port within the pencil lines. Tuck the port's mounting tab under the logic board, plug a charge cable in to check the alignment, then press the port down firmly for 20 seconds
• Before closing the phone, test that it charges, connects to a computer and that the microphone works (record a voice memo)
• Opening your iPhone 17 Pro breaks its factory water-resistance seal. Clean off the old adhesive with isopropyl alcohol, re-seal the microphone gasket (or use 2mm Tesa tape with a hole for the microphone opening) and fit new screen adhesive when you reassemble it
