Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone 16e Screen Replacement Guide

Here are some tools you may need to help you complete the repair.

Please note: A discounted simple toolset with the tools you need is available in a pop-up when you add this product to cart

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2 and Y000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
• 1mm Tesa Tape 61395 Roll Double Sided Adhesive Tape (50m)
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iGadget Universal Magnetic Work Project Mat with Marker (30cm x 25cm)

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it. The battery can't be disconnected from the front on the iPhone 16e or iPhone 17e, so use only plastic tools near the connectors and don't touch exposed contacts
• Track your screws on a screw mat or tape them to a drawing of your phone. This repair uses two 7.8mm pentalobe screws and four Y000 tri-point screws (two 0.9mm and two 1.4mm). Keep them apart so each goes back in the right place
• Remove the two 7.8mm pentalobe screws either side of the USB-C port, then heat the bottom edge to soften the adhesive
• Slide picks under the plastic bezel, not between bezel and panel, no deeper than 3mm. Work along the bottom, right, top and then left edge, heating each edge first. The screen opens from the right like a book - the two display cables are on the left near the Action button
• Lift the front sensor cover and the screen connector cover (one 0.9mm Y000 screw each), then disconnect the screen connector first and the front sensor connector second. When reconnecting, line each up and press one side, then the other, until it clicks - don't force it
• Transfer the front sensor assembly (ambient light sensor, proximity sensor and microphone) from your old screen - the earpiece and the Face ID camera stay in the phone. Remove its bracket (two 1.4mm Y000 screws), warm the top edge for about 2 minutes, gently lift the sensors with a spudger or opening card and re-stick the cable with Tesa tape. A damaged cable stops auto-brightness and the proximity sensor working
• Test touch, display, proximity (screen turns off during a call), auto-brightness and Face ID before sealing the phone, and don't peel off the protective film or any stickers until it's all working
• Clean off all the old adhesive with isopropyl alcohol and fit the new screen adhesive supplied in the box to keep dust and moisture out. Lower the screen straight down, press until all the clips engage and keep it pressed or weighted for at least 30 minutes
• This screen supports IC transfer - a micro-soldering specialist can move the display IC from your old screen onto this one.
• Once the repair is finished, turn True Tone on in Settings > Display & Brightness and check auto-brightness is working (iOS 18 or later)
