Check out the video above or the step by step guide below for assistance with this repair

iFixit Samsung Galaxy S23 Screen and Battery Assembly Replacement Guide

The iFixit guide uses a part with the battery already fitted.

Here are some tools you may need to help you complete the repair.

• #00 Metal Phillips 2.0mm Screwdriver Tool (PH00)
• uFix iOpener Microwaveable Heated Bag Opening Tool
• Large Blue Suction Cup Opening Tool
• iSclack Evo (Gen 3) Suction Cup Opening Tool by Dottorpod
• iGadget 5 piece opening picks
• 5x iGadget Plastic Flexible Opening Cards
• iPlastix Flexible Opening Tool by Dottorpod
• Nylon Antistatic Spudger Pry Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• Box of Isopropyl Adhesive Cleaning Alcohol Pad Wipes x100
• 2mm Tesa Tape 61395 Roll Double Sided Adhesive Tape (100m)

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Power the phone off and take out the SIM tray before you open it. The SIM card reader is on the charging port board, so the board can't come out with the tray still in.
• The back glass is glued on. Warm the edges gently with the iOpener in short bursts, as too much heat can damage the battery, then lift a corner with the suction cup or iSclack and slice the adhesive with a pick no more than 3 to 5mm in, or you can cut the wireless charging coil, antenna or camera cables.
• Always track your screws (Phillips #00) so they go back in the right place. Draw a picture of your phone and tape the screws to it, or use a screw mat
• Always unplug the battery before you remove any other parts. Keep metal tools away from the battery, and never bend, crush or puncture it.
• Move the motherboard, charging board, cameras, earpiece, loudspeaker, wireless charging coil and antennas from your old frame into the new one. The front camera is glued in, so warm it briefly and lift it slowly.
• The battery is not included, so transfer your old one or fit a new one. Lift the old battery out slowly by its pull tabs, and use isopropyl alcohol only if a tab tears.
• Test the display, touch, in-display fingerprint reader (you may need to set it up again), cameras and calls before you close the phone up, and leave the protective film and stickers on until the new screen is working properly.
• Opening the phone breaks the factory water resistance seal. Fit a strip of 2mm Tesa tape where the old adhesive was, then press the back glass down all the way round so it sits flat and stays secure.
