Check out the video above for assistance with this repair

Here are some tools you may need to help you complete the repair.

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• #000 1.5mm Metal Phillips Screwdriver Tool (PH000)
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2, Y000 and #000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adapter by Dottorpod
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iPhone 12 Pro Max OLED Water Resistant Screen Gasket Adhesive

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• Always track your screws to avoid putting back in the wrong place and damaging your device. You can draw a picture of your phone and tape the screws to the right places or use a screw mat
• Remove the two P2 pentalobe screws beside the Lightning port, warm the bottom edge and lift the screen from the front with a suction cup. Keep picks no more than 3mm deep (2mm on the left edge, where the display cables run). The screen opens like a book from the right side
• Make sure you always unplug the battery before attempting any component removal. On the iPhone 12 Pro Max the battery and display connectors sit under a bracket held by Y000 screws: disconnect the battery first, then the display cables, and reconnect the battery last
• The loudspeaker and Taptic Engine sit at the bottom of the phone and come out before you can reach the charging port. Watch the video above for the full order of work
• The connector to the logic board can be tricky to align correctly so it fits into place. We recommend taking a pencil and tracing the original charging port so you know exactly where it gets positioned and lining the new charger port within the pencil lines
• Before sealing the phone, test charging with the cable both ways round, a computer connection, and the bottom microphone (record a Voice Memo)
• Clean off the old screen adhesive with isopropyl alcohol and fit new screen adhesive when you reassemble, as opening the phone breaks its factory water-resistance seal
