Check out the video above or the step by step guide below for assistance with this repair

iFixit iPhone SE 2022 Lightning Connector Assembly Replacement Guide

Here are some tools you may need to help you complete the repair.

• P2 Metal Pentalobe 0.8mm Screwdriver Tool
• Y000 Metal Triwing Tri-Point 0.6mm Screwdriver Tool
• #000 1.5mm Metal Phillips Screwdriver Tool (PH000)
• Large Blue Suction Cup Opening Tool
• Mechanic AK-15 King ESD Anti-Static Stainless Steel Red Curved Tweezers
• iGadget Plastic Triangle Opening Picks (set of 5)
• 5x iGadget Plastic Flexible Opening Cards
• Nylon Antistatic Spudger Pry Tool
• Or get the P2, Y000 and #000 screwdrivers, suction cup, tweezers, opening pick, opening card and spudger together in our 8 Piece iPhone Repair Toolkit
• Metal Stand-Off 2.5mm Screwdriver Tool
• iSclack Evo (Gen 3) Suction Cup Opening Tool for phones and tablets by Dottorpod
• uFix iOpener Microwaveable Heated Bag Opening Tool
• iHold Evo Screen Holding Opening Tool for iPads and iPhones with USB-C Adatper by Dottorpod
• iGadget Plastic Alcohol 200mL Bottle with Pump Top
• iPhone 8/iPhone SE 2020/iPhone SE 2022 LCD Water Resistant Screen Gasket Adhesive

Here are some helpful tips to assist you in completing a safe repair on your device. If you are unsure of something or have any questions, please feel free to contact us either by phone (0508 IGADGET) or by email

• Drain the battery below 25% before you start on this repair
• Always power down your device prior to working on it
• Track your screws, they are many different lengths: two 3.4mm P2 pentalobe screws at the bottom edge, then small Phillips, Y000 and standoff screws inside. Draw a picture of your phone and tape the screws to the right places or use a screw mat
• Remove the SIM tray and the two pentalobe screws beside the Lightning port, warm the screen and lift it from the bottom edge (near the home button) with a suction cup. Slide an opening pick around the sides, no more than 3mm deep on the right edge where the display cables run, and don't pry the top edge, which is held by clips. Don't lift the bottom more than 15 degrees, then slide the screen slightly towards the port and open it like a book from the left
• Make sure you always unplug the battery before attempting any component removal. On the iPhone SE 2022 remove the lower display cable bracket and disconnect the battery first, then the display and front sensor cables, and reconnect the battery last
• The charging port sits under the logic board. The Wi-Fi diversity antenna, Taptic Engine, barometric vent, loudspeaker and logic board all come out to reach it, so unplug every connector on the logic board before lifting it out
• The port flex is glued in and runs along the bottom of the battery and past the wireless charging coil. Warm the bottom of the case and free it slowly with a plastic pick, and never push a pick into the battery
• The connector to the logicboard can be tricky to align correctly so it fits into place. We recommend taking a pencil and tracing the original charging port so you know exactly where it gets positioned and lining the new charger port within the pencil lines. Line the hole in the flex up with the screw post before you press the new flex down
• Move the rubber gasket and the antenna converter cable across from your old port if the new one does not have them, and fit new microphone adhesive patches to keep out dust and liquid
• Before closing the phone, test that it charges, connects to a computer and that the microphone works (record a voice memo)
• Opening your iPhone SE 2022 breaks its factory water-resistance seal. Clean off the old adhesive with isopropyl alcohol and fit a new screen adhesive seal when you reassemble it
